Rigid Sphere without protection Ø12,5 mm y Ø50 mm - IP2X + IP1X - IEC 60529 + IEC 61032
  • prev
  • Next





The Rigid Sphere Ø 50 mm without protection, is used for the verification of the protection degree of mechanical provided by enclosures (housing or cabinet) of equipment in compliance with the first digit No. 1 (IP1X) according to the IEC 60529.

The device is a metal sphere Ø 50 mm with surface finish. Their use is described in Table 6 of IEC 60529. It is the same area of Figure 5 - Test Probe 1 - of IEC 61032.

The Rigid Sphere Ø 12.50 mm without protection, is used for the verification of the protection degree of mechanical provided by enclosures (housing or cabinet) of equipment in compliance with the first digit No. 2 (IP2X) according to the IEC 60529.

The device is a metal sphere Ø 12.50 mm with surface finish. Their use is described in section 13.2 of IEC 60529. It is the same area of Figure 6 - Test Probe 2 - of IEC 61032.

Devices Specifications:
Material: Latón.
Finish:

Chrome plating.

Diameters:
  • Ø 12,5 mm
  • Ø 50 mm
According to:
  • Figure 5 (Test Probe 1) of IEC 61032.
  • Figure 6 (Test Probe 2) of IEC 61032.
  • IEC 60529.
